KATY INSTRUMENTS Model 3P AC Current Sensor 5A, 5-40VDC, 4-20mA NSMP
$375.00
KATY INSTRUMENTS Model 3P AC Current Sensor 5A, 5-40VDC, 4-20mA NSMP
|
STANDARD CURRENT RANGES A.C. Amps, RMS |
||
| 5A |
| PERFORMANCE SPECIFICATIONS with Optimum Load Resistance | |
| Accuracy | 0.2% (Standard) |
| Repeatability | 0.1% Full Scale |
| Response Time | 150 Milliseconds Maximum |
| Temperature Range | -25°C to 85°C |
| Temperature Coefficient | 0.04% F.S./°C |
| Conductor Cable Voltage | 5000 Volts |
| Supply Voltage | 5 to 40 V.D.C |
| Signal Out | 4 to 20 m.A. |
| Frequency | Nominal 50/60 Hz |
| CONNECTION SPECIFICATIONS | |
| Conductor Cable Size | Up to 0.65" diameter |
| Wire Range - Top Terminal | 14 to 22 AWG |
| Dielectric Withstand | 16 KV/mm |
| ADDITIONAL SPECIFICATIONS | |
| Max Weight (unit) | 9 oz. |
CONDITION: NSMP - New Surplus Manufacturer Package (OEM)
WARRANTY: 120 DAYS
SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST.
(CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT)
