NWL Relay Board D20651-01 Rev B | S-RAP-NON DSP Configuration | PWB# P23290

Technical Specifications:

• Model Number: D20651-01 (D2065101)

• PWB/Assy Number: P23290

• Revision: Rev B

• System Category: S-RAP-NON DSP Module

• Application: Part of the NWL Environmental Technologies Graphic Rapper Controller (GRC) and ESP power optimization systems.

• Function: Orchestrates relay timing and rapper control sequences for air pollution control equipment.

Key Features:

• Industrial Reliability: Built to the rigorous standards of NWL Environmental Technologies for continuous operation in power plants and industrial facilities.

• Precise Control: Specifically designed for the non-DSP rapper configuration, ensuring accurate timing for electrostatic precipitator cleaning cycles.

• Legacy Compatibility: High-quality Rev B board that serves as a direct replacement for failing boards in established GRC installations.

• Robust PCB Design: Professional-grade circuit board layout (P23290) optimized for signal integrity and heat dissipation.
