PRO-FACE FGW-SE41-24V Factory Gateway 3080034-01 Network Protocol Converter 24V
$249.95
PRO-FACE FGW-SE41-24V Factory Gateway 3080034-01 Network Protocol Converter 24VKey Features:
- Universal Connectivity: Connects diverse control devices (Allen-Bradley, Siemens, Mitsubishi, Omron, etc.) to a centralized Ethernet network.
- Dual Serial Ports: Features both an RS-232C (D-Sub 9) and an RS-422/485 (Terminal Block) port for maximum flexibility.
- Compact DIN Rail Design: Fits easily into standard control cabinets with minimal space requirements.
- CF Card Expansion: Integrated CompactFlash slot for data logging, recipe storage, or firmware backups.
- Rugged Industrial Build: Fanless design with high noise immunity, engineered for 24/7 operation in harsh factory environments.
Technical Specifications (2025 Data):
| Feature | Detail |
|---|---|
| Manufacturer | Pro-face (Digital Electronics Corp) |
| Part Number | FGW-SE41-24V / 3080034-01 |
| Rated Voltage | 24 VDC (19.2 to 28.8 VDC) |
| Power Consumption | 8W or less |
| Ethernet Port | IEEE802.3 10BASE-T (RJ-45) |
| Serial Port 1 | RS-232C (D-Sub 9-pin) |
| Serial Port 2 | RS-422/485 (12-pin Terminal Block) |
| Weight | Approx. 0.5 kg (1.1 lbs) |
CONDITION: NSMP - New Surplus Manufacturer Package (OEM)
WARRANTY: 120 DAYS
SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST.
(CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT)
