Schmersal 101112628 BNS 33-11Z-2063 Coded Magnetic Safety Sensor 1 NO 1 NC IP67
$109.95
Schmersal 101112628 BNS 33-11Z-2063 Coded Magnetic Safety Sensor 1 NO 1 NC IP67
Product Description
This listing is for one non-contact coded magnetic safety sensor, also known by the type designation
BNS 33-11Z-2063
. This safety device is designed to monitor the position of movable safety guards (doors, gates, covers) in industrial environments. It offers a long life with no mechanical wear and is highly resistant to soiling.
NOTE: This listing is for the sensor unit only. It requires a compatible coded magnetic actuator (e.g., BPS 33 or BPS 33-2326 models, sold separately) to function correctly. Conventional magnets are not suitable for operating this coded safety switch.
- Brand: Schmersal
- Part Number:
- Type Designation:
- Sensing Principle: Coded Magnetic Drive (Reed contacts)
- Contact Configuration: 1 NO (Normally Open) + 1 NC (Normally Closed)
- Operating Voltage: Max. 120 VAC/DC
- Max Switching Current: 500 mA
- Connection: 1 meter (approx. 3.3 ft) pre-wired PVC cable
- Housing Material: Glass-fiber reinforced thermoplastic enclosure
- Environmental Ratings: IP67 (Dust tight and protected against temporary immersion in water)
- Dimensions: 88 mm x 25 mm x 13 mm (L x W x H)
- Coding Level: Low coding according to EN ISO 14119
- Certifications: CE Marked, cURus (UL/CSA approval), BG
Applications
Commonly used in machine safety applications for monitoring the position of guards, covers, and doors where non-contact and tamper-resistant operation is required.
CONDITION: NSFS - New Surplus Factory Sealed (OEM)
WARRANTY: 120 DAYS
