TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB
TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB
TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB

TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB

$425.00
TIMKEN FAFNIR 3MM201WI SPINDLE ANGULAR CONTACT BALL BEARINGS 3MM201WICRDUL NIB


Dimensions

d - Bore

 12.00 mm0.4724 in

D - Outer Diameter

 32.00 mm1.2598 in

Bearing Width

 10.00 mm0.3937 in

Contact Angle

 25 º

do - Ball Diameter

 5.953252 mm0.234380 in

Basic Load Ratings

C0 - Static Radial Rating

 3700 N830 lbf
Ce - Dynamic Radial Rating1 8500 N1910 lbf

Factors

Limiting Speed (Grease)

 51000 rpm

Limiting Speed (Oil)

 102000 rpm

Specifications

Ball Type

 STEEL

Cage Type

 CR - Phenolic Outer Land Riding Cage

Bearing Weight

 0.036 Kg0.080 lb

Design Units

 METRIC

Abutment and Fillet Dimensions

R - Inner Ring "To Clear" Radius2 0.60 mm0.024 in
r - Outer Ring "To Clear" Radius3 0.60 mm0.024 in

da - Inner Ring Backing Diameter

 16.4 mm0.650 in

Da - Outer Ring Backing Diameter

 28.100 mm1.110 in


______________________________________________________________________________________________________________________________________________________________________________________________________________________________________
