Falk 0794377 | 5203J25A Quadrive Shaft Mount Speed Reducer Gear Drive 25:1 Ratio
$3,150.00
Falk 0794377 | 5203J25A Quadrive Shaft Mount Speed Reducer Gear Drive 25:1 Ratio NSMP
This listing is for a brand-new
Falk 5203J25A
. The Falk Quadrive Series is the industry standard for shaft-mounted drives, featuring a rugged parallel helical design for high-load applications. This unit includes severe-duty, grease-purged Viton (FKM) seals to provide maximum protection in extreme environments.Product Details:
Technical Specifications
- Brand: Falk (Regal Rexnord)
- Model: 5203J25A / 5203-J25A
- UPC: 782934259074
- Part Number: 0794377
- Reducer Size: 5203
- Nominal Ratio: 25:1
- Exact Ratio: 26.94:1
- Input Type: Solid Shaft (Double Reduction)
- Input Shaft Diameter: 1.375 in (1-3/8")
- Input Shaft Length: 3.0 in
- Maximum Output RPM: 70 RPM (at 1750 RPM input)
- Maximum Input HP: ~10 HP (varies by service factor)
- Bore Range (Max): 2.1875 in (Requires TA Taper Bushing)
- HSS to LSS Centerline: 4.07 in
- Housing Material: Rugged Cast Iron
- Seal Material: Viton (High-Temperature/Chemical Resistant)
- Weight: Approximately 135 lbs
CONDITION: NSMP - New Surplus Manufacturer Package (OEM)
WARRANTY: 120 DAYS
SAME DAY SHIPPING AVAILABLE ON ORDERS MADE BEFORE 4PM EST.
(CAN SHIP COLLECT ON UPS OR FEDEX ACCOUNT)
