DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP

DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP

$500.00
DODGE 15Q30L56 TIGEAR RIGHT ANGLE WORM GEAR REDUCER 30:1 RATIO 0.51HP INPUT NSNP

  • Center Distance
    1.5000 in
  • Ratio
    30:1
  • Max Input Horsepower
    0.760 hp
  • Case Included
    Yes
  • Horsepower Rating Normal Duty
    Output 0.38 hp
  • Input Type
    C-Face Quill
  • Output Bore Type
    Left
  • Output Type
    Solid
  • Output Size
    0.7500 in
  • Output Direction
    Left Hand
  • Style
    Quill
  • Housing Material
    Cast Iron
  • UPC_NO
    782475745302
  • Input Style
    Quill
  • Lubrication
    PAG, Standard Temperature
  • Nominal Ratio
    30 : 1
  • Output
    Solid
  • Paint Type
    Standard
  • Sealing Type
    Single-Lip Contact
  • Shaft Diameter
    Output 0.75 in
  • Shaft Length
    Output 2.23 in
  • Torque Rating (in-lb)
    Output 413 inch pound (pound inch)
  • Thermal Horsepower Rating
    0.96 horsepower
  • Suitable For Washdown Environment
    No
  • Overhung Load
    710 lbf
  • Gearbox Component Type
    Gearbox
  • Case Size
    15
  • Product Compatibility
    NEMA Motor, 56C Frame

CONDITION: NEW SURPLUS NO BOX

WARRANTY: 120 DAYS

SAME DAY SHIPPING AVAILABLE ON ALL ORDERS MADE BEFORE 4PM EST
